DL192F
JDL
Air cooled diesel engine
14hp
3000/3600rpm
Single cylinder
| Quantity: | |
|---|---|
Low fuel consumption
With new tip-clearance fuel pump and bottom inertia injection technology, combine new type combustor and high burning rate, its fuel economy is much lower than gasoline engines.
Well-designed gear transmission structure, make the vibration decreased and noise lowed, patented air cleaner, lower the noise of air inlet and outlet.
Safe and reliable
Excellent production process, strict QC system to make sure the products safe and reliable.
Model | DL192F/FE |
Engine Type | 1 -Cylinder,4-Stroke, Air-cooled,Vertical |
Combustion System | Direct injection |
Broke*Stroke mm | 92*75 |
Displacement L | 0.499 |
Compression Ratio of diesel engine | 19.5:1 |
Rated Speed rpm | 3000 3600 |
Rated Power KW | 7.6 8.6 |
Rated Power hp | 10.3 11.7 |
Starting System | F:Recoil start E:Electric start |
Fuel Tank Capacity L | 5.5 |
Lube Oil Capacity L | 1.65 |
Fuel Consumption g/kwh | 275 280 |
Fuel Type | 0#(summer),-10#(winter) Diesel oil |
Lube Type | SAE10W30(CD grade or above) |
Overall Diemension (L*W*H)mm | 520*460*540 |
Net Weight kg | F:50 FE:55 |
Rotation Direction (View from Flywheel) | Clockwise |
Low fuel consumption
With new tip-clearance fuel pump and bottom inertia injection technology, combine new type combustor and high burning rate, its fuel economy is much lower than gasoline engines.
Well-designed gear transmission structure, make the vibration decreased and noise lowed, patented air cleaner, lower the noise of air inlet and outlet.
Safe and reliable
Excellent production process, strict QC system to make sure the products safe and reliable.
Model | DL192F/FE |
Engine Type | 1 -Cylinder,4-Stroke, Air-cooled,Vertical |
Combustion System | Direct injection |
Broke*Stroke mm | 92*75 |
Displacement L | 0.499 |
Compression Ratio of diesel engine | 19.5:1 |
Rated Speed rpm | 3000 3600 |
Rated Power KW | 7.6 8.6 |
Rated Power hp | 10.3 11.7 |
Starting System | F:Recoil start E:Electric start |
Fuel Tank Capacity L | 5.5 |
Lube Oil Capacity L | 1.65 |
Fuel Consumption g/kwh | 275 280 |
Fuel Type | 0#(summer),-10#(winter) Diesel oil |
Lube Type | SAE10W30(CD grade or above) |
Overall Diemension (L*W*H)mm | 520*460*540 |
Net Weight kg | F:50 FE:55 |
Rotation Direction (View from Flywheel) | Clockwise |
