DGP80CB
JDL
13HP
3600
OPEN
Availability: | |
---|---|
Quantity: | |
Features
Moves liquids at a rate of 22,500 gallons/hour (375 GPM)
Maximum elevation of 89 ft
Handles solids up to 1.5"
Silicone carbide mechanical seals, 100x Stronger than standard ceramic seals
Chrome plated volute is 12x harder than cast iron
Vibration isolation mounts improving performance and pump stability
Specifications
Engine: 8 HP (5.9kW)
Displacement: 270 cc
Maximum RPM: 3,600 RPM
Diameter of Input/Output: 3 x 3 in.
Nominal Flow: 375 GPM
Nominal Elevation: 89 ft.
Suction: 25 ft.
Oil Capacity: 1.16
…
Engine type | DL210 |
Displacement | 212CC |
(mm) Inlet/Outlet Diameter | 80 |
Rated output Power(hp) | 7.0HP |
(rpm) Speed | 3600 |
(m³/h) Flux | 52 |
(m) Suction Head | 7 |
(m) Max Lift | 25 |
(KGS) N.W./G.W. | 34/36 |
(mm) CTN Size | 555*450*420 |
Features
Moves liquids at a rate of 22,500 gallons/hour (375 GPM)
Maximum elevation of 89 ft
Handles solids up to 1.5"
Silicone carbide mechanical seals, 100x Stronger than standard ceramic seals
Chrome plated volute is 12x harder than cast iron
Vibration isolation mounts improving performance and pump stability
Specifications
Engine: 8 HP (5.9kW)
Displacement: 270 cc
Maximum RPM: 3,600 RPM
Diameter of Input/Output: 3 x 3 in.
Nominal Flow: 375 GPM
Nominal Elevation: 89 ft.
Suction: 25 ft.
Oil Capacity: 1.16
…
Engine type | DL210 |
Displacement | 212CC |
(mm) Inlet/Outlet Diameter | 80 |
Rated output Power(hp) | 7.0HP |
(rpm) Speed | 3600 |
(m³/h) Flux | 52 |
(m) Suction Head | 7 |
(m) Max Lift | 25 |
(KGS) N.W./G.W. | 34/36 |
(mm) CTN Size | 555*450*420 |
